Celduc SGT 1G Series Solid State Relay, 75 A Load, Panel Mount, 600 V ac Load, 24 V ac Control

RS-artikelnummer:: 776-7707
Tillv. art.nr:: SGT967760E
Tillverkare / varumärke:: Celduc

Celduc SGT 1G Series Solid State Relay, 75 A Load, Panel Mount, 600 V ac Load, 24 V ac Control

2 I lager för avsändande samma dag

Nästa dag-leverans inte möjlig

Lagt till varukorgen

Pris (ex. moms) Varje

3 171,58 kr

(exkl. moms)

3 964,48 kr

(inkl. moms)

Enheter	Per unit
1 - 4	3 171,58 kr
5 - 9	3 044,68 kr
10 +	2 981,33 kr

RS-artikelnummer:: 776-7707
Tillv. art.nr:: SGT967760E
Tillverkare / varumärke:: Celduc

Datablad

Lagstiftning och ursprungsland

COO (Country of Origin):: FR

Produktdetaljer

Synchronous, Three-phase Solid State Power Relays

The SGT range of synchronous three-phase solid state power relays have a low leakage current are ideal for resistive loads and offer an unlimited number of operations.

Control range: 4-32 Vdc with current regulation
Integrated LED display
Integrated RC and varistor network
Operating temperature range -40 → +100 °C

Instantaneous Switching

Note

Temperature can affect current rating; please consult the data sheet for potential derating.

Specifikationer

Attribute	Value
Maximum Load Current	75 A
Mounting Type	Panel Mount
Maximum Load Voltage	600 V ac
Minimum Load Voltage	24 V ac
Maximum Control Voltage	24 V ac
Minimum Control Voltage	10 V ac
Switching Type	Zero Cross
Control Voltage Range	10 → 24 V ac
Range	SGT
Minimum Load Current	5 mA
Number of Poles	3
Terminal Type	Screw
Output Device	Thyristor
Relay Type	Three Phase
Load Voltage Range	24 → 600V ac
Maximum Turn On Time	30ms
Series	SGT 1G
Dimensions	100 x 75.15 x 46mm
Maximum Operating Temperature	+100°C
Depth	75.2mm
Off State Leakage Current	1 mA
Minimum Operating Temperature	-40°C
Operating Temperature Range	-40 → +100°C
Length	100mm
Standards Met	CE, EAC
Special Features	Green LED Visualization on The Input
Height	46mm
