onsemi FSL518HPGOS, High Performanceer Power Switch IC 7-Pin, PDIP
- RS-artikelnummer:
- 195-8829
- Tillv. art.nr:
- FSL518HPG
- Tillverkare / varumärke:
- onsemi
3000 I lager för avsändande samma dag
Lagt till varukorgen
Pris (ex. moms) Var (i ett paket med 20)
13,96 kr
(exkl. moms)
17,45 kr
(inkl. moms)
| Enheter | Per unit | Per Pack* |
| 20 + | 13,96 kr | 279,20 kr |
- RS-artikelnummer:
- 195-8829
- Tillv. art.nr:
- FSL518HPG
- Tillverkare / varumärke:
- onsemi
Datablad
Lagstiftning och ursprungsland
Produktdetaljer
The FSL5x8A/H is an integrated peak-current-mode controlled pulse width modulation (PWM) power switch, specifically designed for off-line switch-mode power supplies. The PWM controller includes an advanced soft-start, frequency hopping, optimized gate driver, internal transconductance amplifier, temperature-compensated precise current source for loop compensation and enhanced self-protections circuitry as well. This device provides a basic platform for cost-effective design of both isolated and non-isolated Flyback converters.
Specifikationer
Attribute | Value |
|---|---|
| Power Switch Type | High Performanceer |
| Maximum Operating Current | 2mA |
| Mounting Type | Through Hole |
| Package Type | PDIP |
| Pin Count | 7 |
| Maximum Operating Temperature | +125 °C |
| Minimum Operating Temperature | -40 °C |
| Dimensions | 10.16 x 7.11 x 4.95mm |
| Series | FSL518H |
