SMC AKB Non Return Valve NPT 1/4 Female Inlet, NPT 1/4 Female Outlet, -100 kPa → 1 MPa
- RS-artikelnummer:
- 849-7231
- Tillv. art.nr:
- AKB02B-N02S
- Tillverkare / varumärke:
- SMC
3 I lager för avsändande samma dag
Lagt till varukorgen
Pris (ex. moms) Varje
150,33 kr
(exkl. moms)
187,91 kr
(inkl. moms)
| Enheter | Per unit |
| 1 - 4 | 150,33 kr |
| 5 - 9 | 145,60 kr |
| 10 + | 141,07 kr |
- RS-artikelnummer:
- 849-7231
- Tillv. art.nr:
- AKB02B-N02S
- Tillverkare / varumärke:
- SMC
Datablad
Lagstiftning och ursprungsland
Uppfyller ej RoHS
- COO (Country of Origin):
- JP
Produktdetaljer
SMC Vacuum Check Valve
Suitable for vacuum pressures of -0.03 to -0.99 bar
Low cracking pressure of 0.02 bar
Positive and vacuum compatible
Operating temperature range : +5 to +60°C
Available in Mpa measurement
NPT threadform ports (1/8", 1/4" & 1/2") also available
Low cracking pressure of 0.02 bar
Positive and vacuum compatible
Operating temperature range : +5 to +60°C
Available in Mpa measurement
NPT threadform ports (1/8", 1/4" & 1/2") also available
Specifikationer
Attribute | Value |
|---|---|
| Inlet Connection Type | Threaded |
| Threaded Inlet Connection | NPT 1/4 Female |
| Outlet Connection Type | Threaded |
| Manufacturer Series | AKB |
| Threaded Outlet Connection | NPT 1/4 Female |
| Cracking Pressure | 0.005MPa |
| Threaded Inlet Gender | Female |
| Minimum Operating Pressure | -100kPa |
| Maximum Operating Pressure | 1 MPa |
| Maximum Operating Temperature | +60°C |
| Threaded Outlet Gender | Female |
| Threaded Inlet Thread Size | 1/4 |
| Operating Pressure Range | -100 kPa → 1 MPa |
| Threaded Outlet Thread Size | 1/4 |
| Threaded Outlet Thread Standard | NPT |
| Threaded Inlet Thread Standard | NPT |
| Minimum Operating Temperature | -5°C |
