Norgren F72C 0.01μm G 3/8 Pneumatic Filter, Semi Automatic

  • RS-artikelnummer 267-9254
  • Tillv. art.nr F72C-3GD-ST0
  • Tillverkare / varumärke Norgren
Datablad
Lagstiftning och ursprungsland
Ej tillämpbart
COO (Country of Origin): GB
Produktdetaljer

Norgren F74C Series Oil Removal Filter

Norgren Excelon high efficiency oil removal filters. Coalescing element converts oil and water mist into liquid which can then be drained away. Quick release bayonet bowl and service indicator are standard to aid maintenance. Norgren's Excelon range are designed to be used as part of a modular installation with other Excelon products or as a in-line unit with other pneumatic air preparation equipment.

Features and Benefits

  • High efficiency filter which conditions air

  • Temperature range -20°C to +50°C

  • Polycarbonate bowl

  • Element material synthetic fibre and polyurethane foam

  • Remaining oil content 0.01 mg/m³

  • Filtration to 0.01μm

//media.rs-online.com/t_line/L239071-01.gif
//media.rs-online.com/t_line/LE239071-01.gif
//media.rs-online.com/t_line/LF239071-10.gif
//media.rs-online.com/t_line/LI239071-01.gif

Standards

ISO 8573-1 Class 1.7.2

Filters

Specifikationer
Attribute Value
Manufacturer Series F72C
Filtration Size 0.01µm
Drain Type Semi Automatic
Port Connection G 3/8
Typical Flow Rate 4.5L/s
Maximum Operating Pressure 10 bar
Maximum Operating Temperature +50°C
Port Connection Thread Standard G
Minimum Operating Temperature -34°C
Port Connection Thread Size 3/8 in
