Souriau, 851 19 Way Cable Mount MIL Spec Circular Connector Plug, Pin Contacts,Shell Size 14, Bayonet Coupling,
- RS-artikelnummer:
- 687-6695
- Tillv. art.nr:
- 85106T1419P50
- Tillverkare / varumärke:
- Souriau Sunbank by Eaton
33 I lager för avsändande samma dag
Lagt till varukorgen
Pris (ex. moms) Varje
713,51 kr
(exkl. moms)
891,89 kr
(inkl. moms)
| Enheter | Per unit |
| 1 - 4 | 713,51 kr |
| 5 - 24 | 624,35 kr |
| 25 + | 535,18 kr |
- RS-artikelnummer:
- 687-6695
- Tillv. art.nr:
- 85106T1419P50
- Tillverkare / varumärke:
- Souriau Sunbank by Eaton
Lagstiftning och ursprungsland
Uppfyller ej RoHS
Produktdetaljer
Plug for Straight Backshell
Souriau - 851 Series
The 851 connectors feature a positive bayonet coupling mechanism, ensuring reliable mechanical and electrical connection between two mating halves. A helical locking ring on the plug couples with three dowel pegs on the receptacle ensuring rapid locking. Orientation and location is ensured by a system of five raised keys on the plugs which couple with corresponding slots on the receptacles.
Specifikationer
Attribute | Value |
|---|---|
| Number of Contacts | 19 |
| Gender | Male |
| Contact Gender | Male |
| Current Rating | 7.5A |
| Shell Size | 14 |
| Mounting Type | Cable Mount |
| Military Standard | MIL-DTL-26482 |
| Termination Method | Solder |
| Mating Type | Bayonet Coupling |
| Body Orientation | Straight |
| Series | 851 |
| Contact Plating | Gold |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +125°C |
| Shell Plating | Olive Drab Cadmium |
| Contact Material | Copper Alloy |
