- RS-artikelnummer:
- 190-7305
- Tillv. art.nr:
- MAX9176EUB+
- Tillverkare / varumärke:
- Maxim Integrated
- RS-artikelnummer:
- 190-7305
- Tillv. art.nr:
- MAX9176EUB+
- Tillverkare / varumärke:
- Maxim Integrated
Datablad
Lagstiftning och ursprungsland
- COO (Country of Origin):
- TH
Produktdetaljer
1.0ps(RMS) Jitter (max) at 670MHz
68ps(P-P) Jitter at 800Mbps Data Rate
3.3V Supply
LVDS Fail-Safe Inputs (MAX9176)
Anything Inputs (MAX9177) Accept CML/LVDS/LVPECL
Select and Power-Down Inputs Tolerate -1.0V and VCC + 1.0V
Low-Power CMOS Design
10-Lead μMAX and QFN Packages
-40°C to +85°C Operating Temperature Range
Applications
Clock Distribution
Loopback
Protection Switching
68ps(P-P) Jitter at 800Mbps Data Rate
3.3V Supply
LVDS Fail-Safe Inputs (MAX9176)
Anything Inputs (MAX9177) Accept CML/LVDS/LVPECL
Select and Power-Down Inputs Tolerate -1.0V and VCC + 1.0V
Low-Power CMOS Design
10-Lead μMAX and QFN Packages
-40°C to +85°C Operating Temperature Range
Applications
Clock Distribution
Loopback
Protection Switching
Specifikationer
Attribute | Value |
---|---|
IC Type | Multiplexers IC |
Transmission Data Rate | 800Mbps |
Package Type | μMAX |
Pin Count | 10 |
