Peak Electronic Design LLSm LCR Meter Adapter

Datablad
Lagstiftning och ursprungsland
Und.t.
COO (Country of Origin): GB
Produktdetaljer

Peak LCR40m Passive Component Analyser

The LCR40m will automatically identify inductors, capacitors and resistors, measuring the main component value and other componant details (e.g coil inductance and dc resistance). The LCR40m is ideal for unmarked and surface mount designs.

Automatic component identification
Automatic test frequency selection
Delayed or instant analysis (for hands free operation)
Non volatile probe and test lead compensation
Automatic ranging and scaling with real units displayed
Auto and manual power-off

Specifikationer
Attribute Value
Accessory Type Adapter
For Use With LCR Meter
6 I lager för leverans inom 1 arbetsdagar
Pris (ex. moms) Each
223,96 kr
(exkl. moms)
279,95 kr
(inkl. moms)
Enheter
Per unit
1 +
223,96 kr
