Aim-TTi TF960 - 6GHz Universal Frequency Counter

The Aim-TTi TF960 is a 6GHz bench/portable universal counter with USB. It uses a high quality temperature-compensated internal frequency reference (TCXO) which has a low aging rate and is stable to within ±1ppm over the full temperature range. The instrument's short warm-up time enables accurate measurements to be made even under portable battery-powered conditions. An External Reference input is provided and changeover from the internal timebase is automatic when an external reference standard is connected. For frequency, period and frequency ratio functions, the TF960 uses a reciprocal counting technique to provide high resolution at all frequencies. Eight significant digits of answer are produced in a 1 second measurement time, nine digits in 10s and ten digits in 100s, with a granularity of less than 2 counts in the least significant digit.

Frequency, period, pulse width, frequency ratio, duty cycle and event counter modes
DC to 6000MHz range, 0.001mHz resolution
High impedance measurement up to 125 MHz
AC or DC coupling, 1M/50Ohm selection, polarity invert
Switchable attenuator, threshold control
Noise filter for low frequency measurements
Selectable measurement time; display hold function
Large 10 digit display with full range of annunciators
Internal rechargeable batteries for portable use
USB interface provides full remote control and readback

Aim-TTi Frequency Counter

The Aim-TTi frequency counter is a 6GHz, universal benchtop, portable instrument with the USB interface device. This frequency counter can measure frequency, period, pulse width, duty cycle and frequency ratio, as well as perform event counting. It has a USB interface that allows it to be remotely controlled using RS232 protocol via a computer’s USB port. It can also be charged through the USB interface. This frequency counter has 10digit resolution and pulse width resolution is 20ns.

Features and Benefits

• High impedance measurement up to 125MHz
• AC or DC coupling, 1M/50Ohms selection, polarity invert
• Switchable attenuator and threshold control
• Noise filter for low frequency measurements
• Selectable measurement time and display hold function
• Large 10-digit display with full range of annunciators
• Internal rechargeable batteries for portable use
• USB interface provides full remote control and read back

Applications


Data communication
• Embedded systems
• RF and microwaves
• Laboratories

Certifications


EN61010-1
• EN61326

Specifikationer
Attribute Value
Maximum Frequency 6GHz
Minimum Frequency 0.001 Hz
Resolution 10 Digit
Calibrated UKAS
Pulse Width Resolution 20ns
Attenuation 1:1, 5:1
Maximum Internal Counter 9999999999
Minimum Internal Counter 1
Maximum Input Voltage 30V
Input Impedance 1 MΩ, 50 Ω
Measurement Time 100s
Connector Type Type-N
Dimensions 260 x 235 x 88mm
Minimum Operating Temperature +5°C
Height 88mm
Model Number p TF960
Weight 950g
Maximum Operating Temperature +40°C
Width 235mm
Length 260mm
