Hartmann 16 Way Through Hole DIP Switch, Cross Shaped Slot Actuator
- RS-artikelnummer:
- 334-965A
- Tillv. art.nr:
- P60A703
- Tillverkare / varumärke:
- Hartmann
Tillfälligt slut i lager – restorder för leverans 2024-08-05
Lagt till varukorgen
Pris (ex. moms) Var (i ett paket med 50)
30,076 kr
(exkl. moms)
37,595 kr
(inkl. moms)
| Enheter | Per unit | Per Pack* |
| 50 - 50 | 30,076 kr | 1 503,80 kr |
| 100 - 200 | 24,873 kr | 1 243,65 kr |
| 250 - 450 | 23,49 kr | 1 174,50 kr |
| 500 - 950 | 22,077 kr | 1 103,85 kr |
| 1000 + | 20,994 kr | 1 049,70 kr |
- RS-artikelnummer:
- 334-965A
- Tillv. art.nr:
- P60A703
- Tillverkare / varumärke:
- Hartmann
Lagstiftning och ursprungsland
- COO (Country of Origin):
- DE
Produktdetaljer
Cross-head Rotary Encoder
Flux sealed & process washable
Contact rating: 150mA @ 24Vdc
Contact resistance: <80mΩ
Life: >104 operations
Positive detent action
Gold plated contacts
Through hole and Surface mount versions
Contact rating: 150mA @ 24Vdc
Contact resistance: <80mΩ
Life: >104 operations
Positive detent action
Gold plated contacts
Through hole and Surface mount versions
Note
Soldering temperature: 340°C max. for 2s max. (40 watt iron max.) or 260°C for 10s max.
PCB Mounting
Footprint/pin spacing: 2.54mm between pins and 5.08mm between rows
Specifikationer
Attribute | Value |
|---|---|
| Number of Positions | 16 |
| Mounting Type | Through Hole |
| Contact Material | Gold over Nickel Plated Stainless Steel |
| Package Style | DIP |
| Actuator Type | Cross Shaped Slot |
| Contact Current Rating | 150 mA@ 24 V dc |
| Mechanical Life | 10000Operations |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -20°C |
| Operating Temperature Range | -20 → +85°C |
| Voltage Rating | 24V dc |
