Norcomp, 171 9 Way Panel Mount D-sub Connector Plug, 2.77mm Pitch
100 I lager för leverans inom 1 arbetsdagar
Lagt till varukorgen
- RS-artikelnummer:
- 174-8446
- Tillv. art.nr:
- 171-009-103L001
- Tillverkare / varumärke:
- Norcomp
- COO (Country of Origin):
- TW
| Enheter | Per unit | Per Tray* |
| 50 - 50 | 5,797 kr | 289,85 kr |
| 100 - 200 | 5,46 kr | 273,00 kr |
| 250 + | 5,013 kr | 250,65 kr |
| *price indicative | ||
Solder cup d-subs available in 5 industry sizes/positions
Standard Density (9 pin, 15 pin, 25 pin, 37 pin, 50 pin).
Low cost economy series.
Nickel shells have indents to provide grounding and additional retention.
Low cost & high performance, non-removable stamped contacts.
Optional mounting hardware available.
Shell: Steel, Tin or Nickel Plated
Insulator: Glass-filled thermoplastic. (230°C process temp)
Stamped contacts:Male pins - Brass | Female pins - Phosphor bronze
Plating: Gold flash on entire contact
| Attribute | Value |
| Number of Contacts | 9 |
| Gender | Male |
| Body Orientation | Straight |
| Mounting Type | Panel Mount |
| Pitch | 2.77mm |
| D Connector Type | Standard D-Sub |
| Termination Method | Solder |
| Current Rating | 5.0A |
| Housing Material | Steel |
| Voltage Rating | 500.0 V |
| Length | 30.8mm |
| Width | 12.6mm |
| Depth | 9.93mm |
| Dimensions | 30.8 x 12.6 x 9.93mm |
| Minimum Operating Temperature | -50.0°C |
| Contact Plating | Gold Flash |
| Series | 171 |
| Contact Material | Copper Alloy |
| Maximum Operating Temperature | +100°C |
