TE Connectivity Uninsulated Male Crimp Bullet Connector, 0.5mm² to 2.27mm², 20AWG to 14AWG, 3.5mm Bullet diameter

  • RS-artikelnummer 719-6212
  • Tillv. art.nr 170020-1
  • Tillverkare / varumärke TE Connectivity
Datablad
Lagstiftning och ursprungsland
RoHS-Försäkran
Produktdetaljer

TE Connectivity Crimp Bullet Connectors

Crimp bullet connectors made from tin plated brass. These crimp bullet plug connectors have a 3.96mm pin diameter apart from stock number 719-6212 which has a 3.56mm pin diameter and stock number 795-6442 which has a 4.57mm pin diameter.

Shur Plugs and Shur Plug Receptacles

Specifikationer
Attribute Value
Insulation Uninsulated
Overall Length 17mm
Gender Male
Minimum Wire Size mm² 0.5mm²
Maximum Wire Size mm² 2.27mm²
Minimum Wire Size AWG 20AWG
Maximum Wire Size AWG 14AWG
Bullet Diameter 3.5mm
Shrouded/Unshrouded Unshrouded
Contact Plating Tin
Contact Material Brass
950 I lager för leverans inom 1 arbetsdagar
Pris (ex. moms) Each (In a Pack of 50)
1,897 kr
(exkl. moms)
2,371 kr
(inkl. moms)
Enheter
Per unit
Per Pack*
50 +
1,897 kr
94,85 kr
Förpackningsalternativ:
